Can You Fit a Bathtub in a Singapore HDB? Yes, From 800mm.

HERA Team Updated 30 October 2026 10 min read

“Can I even fit a bathtub in my HDB?” is the question we hear most at the showroom. For most HDB bathrooms the answer is yes, and the deciding number is usually your longest clear wall, not the floor area.

The short answer

Yes, a bathtub fits in most HDB bathrooms. HERA freestanding bathtubs start at 800mm long, drain into the floor trap you already have, and install in about 30 to 45 minutes with no hacking, tiling or HDB permit.

Measure your longest clear wall. If it is at least 100 to 200mm longer than the tub, it fits.

Bathtub trivia in under 2 minutes: one-cent baths in 1880s Singapore, a tub over 3,000 years old, and how to check if one fits your HDB bathroom.
Sources for the video
800mm
Our smallest bathtub
30 to 45
Minutes to install, no renovation
300kg
Full load, within HDB floor limits
$1,188
Starting price, free delivery

How much space a bathtub needs in an HDB bathroom

HDB bathrooms vary by flat type, year and whether it is the common or master bathroom, so a floor area tells you little. The number that decides it is the longest stretch of wall with nothing in the way: no door swing, no toilet, no vanity.

Take the tub's length and add 50 to 100mm of clearance on each side for cleaning and movement. An 800mm tub needs a clear wall of about 900 to 1000mm. A 1200mm tub needs about 1300 to 1400mm.

Freestanding bathtub beside a timber vanity and toilet in one bathroom
A tub, vanity and toilet can share one bathroom. Leave 50 to 100mm around the tub so you can clean behind it.

Check three other things while you have the tape out: which way the door swings, where the floor trap sits, and where the water heater and shower mixer are. Each one changes which wall the tub can go on.

HERA bathtubs that fit HDB bathrooms

Most bathtubs in renovation magazines are long rectangles built for the middle of a large room. The HERA range starts much smaller, with four models at 800mm, so a compact common bathroom is usually still an option.

ModelShapeLengthsSmallest size (L × W × H)From
HERA 1010Square, portable800, 900, 1000mm800 × 800 × 630mm$1,188
HERA 1011Corner, portable800, 900, 1000mm800 × 800 × 630mm$1,188
HERA 1012Mini oval800 to 1200mm800 × 650 × 620mm$1,188
HERA 1009Rectangular, seat optional800 to 1300mm800 × 680 × 630mm$1,188
HERA 1017Rectangular with seat900 to 1300mm900 × 590 × 680mm$1,188
HERA 1015Corner, raindrop900 to 1100mm900 × 900 × 630mm$1,188
HERA 1016Soft curve, portable1100 to 1400mm1100 × 700 × 630mm$1,422
HERA 1003Rectangular, portable1200 to 1700mm1200 × 700 × 580mm$1,422
HERA 1001Square, deep soak1100 to 1500mm1100 × 1100 × 600mm$2,188
HERA 1007Round1200 to 1600mm1200 × 1200 × 600mm$2,188

Sizes and prices from the HERA online store, October 2026. “From” is the price of the smallest size. The full range is 16 models in six shapes, from 800mm to 1700mm.

Under 1 metre: for the smallest common bathrooms

The 1010, 1011, 1012 and 1009 all come in 800mm. These are deep, upright soaking tubs: you sit with your knees up rather than lie back, the way a Japanese ofuro works.

HERA 1010 square bathtub under a rain shower in a compact bathroom
HERA 1010 · square800, 900 or 1000mm. From $1,188.
HERA 1012 mini oval bathtub under a rain shower in a compact bathroom
HERA 1012 · mini oval800 to 1200mm. From $1,188.
HERA 1017 rectangular bathtub with a built-in seat in a compact bathroom
HERA 1017 · with seat900 to 1300mm. From $1,188.
HERA 1016 soft-curve bathtub beside a glass shower screen
HERA 1016 · soft curve1100 to 1400mm. From $1,422.

1 to 1.3 metres: room to sit back

The 1017 has a moulded seat, and the 1016 has soft, curved ends that are easier to fit past a door swing than square corners. Both suit a bathroom where one wall has a little more room.

Corner and round tubs: when the corner is the free space

If the only free space is a corner, a corner tub uses it without blocking the middle of the room. The 1011 starts at 800 × 800mm and the 1015 raindrop at 900 × 900mm.

HERA 1011 quarter-round corner bathtub tucked into a bathroom corner
The HERA 1011 corner tub fills a corner that would otherwise stay empty. It starts at 800 × 800mm.

Round and deep square tubs such as the 1007 and 1001 start at 1100 to 1200mm across. They suit a larger master bathroom. For a long oval to lie back in, most condo bathrooms take 1400mm or 1500mm, and many take 1700mm.

Plumbing: why you do not need to hack anything

Every HERA bathtub is freestanding and drains through a flexible outlet into the floor trap your bathroom already has. The floor is already waterproofed and already drains there, so the tub uses the same drain.

The kettle test

If you can pour water from a kettle into your existing floor trap and watch it drain, your bathroom can take a HERA bathtub.

That is the difference from a built-in tub. A built-in tub sits in a tiled apron, needs a waterproof membrane under the tiles, and has its water inlet and drain piped permanently into the floor and walls. That work usually adds $1,500 to $3,000 on top of the tub.

Hot water is the other check. A tub takes more hot water than a shower, so if your instant heater struggles to fill a tub at temperature, budget for a higher-spec heater. Our no-renovation installation guide walks through the 8 steps on the day.

HDB rules: do you need a permit?

Not for a HERA bathtub. The installation involves no structural modification, no plumbing change and no hacking, so no HDB permit is needed. Your existing waterproofing is not disturbed.

A built-in tub is different, because hacking tiles, moving drainage and redoing waterproofing are renovation works. Our guide to HDB bathtub regulations covers what applies when a tub is built in.

Will the floor take the weight?

Yes. A HERA bathtub weighs 30kg to 45kg empty. Filled with water and a person, the total load is about 300kg, per the manufacturer's specification.

  • Within HDB limits: 300kg sits within the standard structural live load capacity of HDB and condo bathroom floors.
  • Spread out: the weight is spread across the whole footprint of the tub, the way a sofa or a full wardrobe is, not pressed into one point.
  • Built for it: each tub is acrylic over fibreglass on a stainless steel frame rated for 300kg.

Getting it through the door

A tub has to travel from the lift lobby, through your unit door and corridor, and into the bathroom. HDB unit doors are typically around 80 to 90cm wide, and bathroom doors are often narrower, sometimes 70cm.

Standard HERA sizes go through standard HDB and condo doorways without any change to the door, and two installers carry the tub from the lift to your bathroom. If a doorway looks tight, compare it with the tub's height as well as its width: 580 to 680mm on the compact models in the table above.

If your flat has a tight turn in the corridor, measure it and send us the numbers before you order.

How to check the fit in 10 minutes

  1. Measure your longest clear wall in millimetres, from corner to door frame or fixture.
  2. Note the door swing and where the floor trap, water heater and shower mixer sit.
  3. Do the kettle test on the floor trap.
  4. Measure each doorway from the lift lobby to the bathroom.
  5. Mark the footprint on the floor with tape or cardboard, using the outer size of the tub, then open the door and walk around it.
Dimension drawing of the HERA 1010 square bathtub in 800, 900 and 1000mm sizes, 630mm tall
The HERA 1010 drawing: 800, 900 or 1000mm square outside and 630mm tall. Compare the outer size with your wall, not the inner basin.

Then put the numbers into our Fit Calculator, which lists the HERA models that fit in under 60 seconds. The AR visualiser places a tub in your bathroom through your phone camera. Or send the measurements on WhatsApp and the team will recommend a size.

BTO, resale and rented flats

  • New BTO flats: the tub connects to the existing floor trap, so the new floor finish and waterproofing stay untouched. There is no hacking, tiling or plumbing work to schedule around your renovation. See bathtubs for BTO flats for the projects we have fitted and the models chosen there.
  • Older resale flats: because nothing is built in, HERA bathtubs work the same way in older HDB flats and walk-up apartments. If your block has HDB upgrading coming, read what HIP covers first.
  • Rented flats: the tub can be disconnected and removed at any time without leaving a trace. Many customers take it with them when they move. Check with your landlord before you order.
HERA 1012 mini oval bathtub next to a vanity and a wall-mounted shower
The HERA 1012 mini oval next to a vanity and shower. A short oval leaves floor space for the rest of the bathroom.

What it costs

ItemCost
HERA bathtubFrom $1,188
Delivery in SingaporeFree
Professional installation$126 to $432, by layout, drainage position and floor level
Optional bathtub filler$150 to $400
Complete setup$1,300 to $2,900

Installation covers delivery into your unit, placement, the drainage connection and a leak test. Every HERA bathtub has a 1-year warranty against manufacturing faults. Full breakdown in our bathtub cost guide.

Running costs are small. A typical 200-litre bath costs roughly $0.30 to $0.40 in water and about the same in heater energy, so a weekly bath comes to less than $40 a year.

When a bathtub is not the right call

  • One bathroom and a busy household. Mornings become a queue, and a shower is faster.
  • The bathroom is the only way to a yard or service area. Do not block your own path.
  • You do not take baths. If you cannot remember the last time you wanted a soak, the tub becomes a shower with high sides.

In those cases, a good walk-in shower and a vanity with proper storage will do more for the room every day.

Questions people ask about HDB bathtubs

Can you have a bathtub in an HDB flat?

Yes. Most HDB bathrooms can take a freestanding bathtub. HERA tubs start at 800mm long, drain into the existing floor trap with a flexible outlet, and install in about 30 to 45 minutes with no hacking, tiling or waterproofing work.

What is the smallest bathtub for an HDB bathroom?

HERA's smallest bathtubs are 800mm long: the 1010 square (800 × 800mm), the 1011 corner (800 × 800mm), the 1012 mini oval (800 × 650mm) and the 1009 rectangular (800 × 680mm). All four start from $1,188.

Do I need HDB approval to install a bathtub?

Not for a HERA freestanding bathtub. The installation involves no structural modification, plumbing change or hacking, so no HDB permit is needed. A built-in tub that needs hacking, tiling and new waterproofing is renovation work and follows HDB's renovation rules.

Can an HDB bathroom floor take the weight of a bathtub?

Yes. A HERA bathtub weighs 30kg to 45kg empty. Filled with water and a person, the total live load is about 300kg, spread across the full footprint of the tub, which is within the standard structural live load capacity of HDB bathroom floors.

Can I install a bathtub in a new BTO flat?

Yes. A HERA bathtub connects to the bathroom's existing floor trap, so the new floor finish and waterproofing are not touched. There is no hacking, tiling or plumbing modification.

Can I put a bathtub in a rented HDB flat?

A HERA bathtub is not fixed to the flat. It sits on the floor and drains into the existing floor trap, and it can be disconnected and removed at any time without leaving a trace, so many renters take it with them when they move. Check with your landlord before you order.

How much does a bathtub for an HDB cost in Singapore?

HERA bathtubs cost from $1,188, with free delivery in Singapore. Professional installation is $126 to $432 depending on the bathroom layout, drainage position and floor level. A complete setup usually comes to $1,300 to $2,900.

Next step

Run the Fit Calculator with your wall measurement, then compare the HERA bathtubs it suggests. To see them in person, visit the showroom at 601 MacPherson Road, #04-24 Grantral Mall.

If you would rather have us measure, book a site visit. It is a $30 on-site consultation, which is not refundable, and you receive a $108 voucher to use on HERA products. The team checks dimensions, drainage and access, and tells you which size fits.

Not sure which size?

Book a site visit. We’ll tell you what fits.

Our team measures your bathroom, checks the floor trap and access, and recommends a size, with no obligation to buy.
